Cyfelco SRB is to engineered to address the requirements of the food processing industry and comply with FDA guidelines. The corrosion resistant and non-toxic aluminum exterior is completely smooth and easy to clean. Its IP69K ingress protection rating (protection against high temperature steam and high pressure water) allows for usage in areas with high humidity and makes it washdown capable.

The Cyfelco SRB complies to the following European Directives and Standards:
ISO 9001:2015 Quality Management System,
2014/35/EU Low Voltage Directive,
2014/30/EU Electromagnetic Compatibility Directive,
2011/65/EU RoHS Restrictions of Hazardous Substances Directive,
EN 60598-1:2015 Luminaires - General requirements and tests,
Additional:UL, DLC, NSF Food certifications.

High efficiency up to 130Lm/W.
Designed for food processing areas
Complete smooth surface for easy cleaning
Unique internal thermal management structure
IP69K rated for most environmental conditions
High quality polycarbonate optics

We provide lighting solutions with the use of design and lighting software to achieve the lowest possible running and maintenance cost to minimize the level of the initial investment.

Options Upon Request:
Dimmable 1-10V
Optional honeycomb reflector for glare reduction
Built-in microwave sensor
ZIGBEE

Code
Description
Nominal Voltage
(Lm/W)
Nominal Flux (Lumen)
Beam Angle
LED Quantity
Ingress Protection
Impact Protection
CRI
952-024 CYFELCO SRB 100W 840 AC100~277V, 50~60Hz 130 13000 110° 196 PCS, EMC 3030 IP69K IK10 >80
952-020 CYFELCO SRB 100W 840 <19 AC100~277V, 50~60Hz 130 13000 60° 196 PCS, EMC 3030 IP69K IK10 >80
952-021 CYFELCO SRB 100W 850 AC100~277V, 50~60Hz 130 13000 110° 196 PCS, EMC 3030 IP69K IK10 >80
952-028 CYFELCO SRB 100W 850 <19 AC100~277V, 50~60Hz 130 13000 60° 196 PCS, EMC 3030 IP69K IK10 >80
952-025 CYFELCO SRB 150W 840 AC100~277V, 50~60Hz 130 19500 110° 252 PCS, EMC 3030 IP69K IK10 >80
952-022 CYFELCO SRB 150W 840 <19 AC100~277V, 50~60Hz 130 19500 60° 252 PCS, EMC 3030 IP69K IK10 >80
952-023 CYFELCO SRB 150W 850 AC100~277V, 50~60Hz 130 19500 110° 252 PCS, EMC 3030 IP69K IK10 >80
952-029 CYFELCO SRB 150W 850 <19 AC100~277V, 50~60Hz 130 19500 60° 252 PCS, EMC 3030 IP69K IK10 >80
952-026 CYFELCO SRB 200W 840 AC100~277V, 50~60Hz 130 26000 110° 336 PCS, EMC 3030 IP69K IK10 >80
952-030 CYFELCO SRB 200W 840 <19 AC100~277V, 50~60Hz 130 26000 60° 336 PCS, EMC 3030 IP69K IK10 >80
952-027 CYFELCO SRB 200W 850 AC100~277V, 50~60Hz 130 26000 110° 336 PCS, EMC 3030 IP69K IK10 >80
952-031 CYFELCO SRB 200W 850 <19 AC100~277V, 50~60Hz 130 26000 60° 336 PCS, EMC 3030 IP69K IK10 >80
